What do architectural drawings usually contain?

Blog what do architectural drawings usually contain

A set of working drawings provides the specifics necessary to show how a construction project will meet building codes and demonstrate its structural integrity. Professional quality drafting supplies are vital to creating clear and accurate plans.

Architectural drawings typically contain the following:


Blog what do architectural drawings usually contain

A foundation plan drawn using quality architecture supplies provides an overview of the project with essential structural information, such as:
  • The type and width of the foundation wall
  • The size of the footings
  • Details about point loads
  • Construction techniques

Floor Plans

An architect draws these plans as a horizontal cross-section, showing the rooms, doors and windows. They contain a great deal of essential information. Indicate the size of each room, the location of appliances, plumbing fixtures, fireplaces and more. Include particulars about things like the framing components, materials, fixtures and cabinets. A floor plan will also specify information about garages, decks and other exterior features and demonstrate how the building meets fire code.

Windows and Doors

Sometimes, an architect may create framing sheets for walls, windows, doors and floors separately. This information could be in the form of a drawing or a document.


This plan provides a visual aid with information about ceiling heights, exterior finishes and the roof slope. It has scaled views of the building's outside, displays overhangs and the necessary techniques and materials to finish the exterior. An elevations plan details how it complies with codes and lists the roof slope ratio.

Roof Framing

These plans enable the builder to see details about the elements used to frame the roof, including each structural member's size and location. Also included are connectors, venting, overhangs and the rafter's size and spacing.

Section Views

This plan type contains precise information about the design and construction features, such as floors, walls and heights, including large and small cross-section views to show various vital components. It is critical to include all particulars and structural details with any necessary notes.

Construction Details

Include a drawing plan for any additional architectural details, if needed. You can include assembly information about junctions and connections and highlight areas that require different materials or need attention. These detailed drawings can also show building code requirements and other crucial information. Some architectural plans need less of these added specifics than others, but it is often best to offer as many details as possible.

Electrical Plans

An electrical plan guides the builder with particulars concerning outlets, light fixtures, switches, smoke detectors and code requirements.

Additional Plans

Your project may include other drawings, such as:
  • Landscaping
  • External drainage
  • Reflected ceiling

Shop Drafting Supplies

Frequently Asked Questions

What are some standard useful drafting tools?

Blog what do architectural drawings usually contain

  • Drafting paper: This specialty paper is available in various materials for optimal results.
  • Pens: Obtain a technical pen set to ensure precise line thickness.
  • Desk Lamp: Increase your accuracy and productivity with the right lighting.
  • Architect's scale: This triangular tool is lightweight and durable, featuring six scales with embossed measurements.

Where can I buy drafting paper?

Engineer Supply has a wide selection of top, reliable paper brands ideal for architects. They have blueprint paper, grid drawing paper and drafting vellums plus wide-format solutions for large printers, available in sheets and rolls. Choose from various formats and types to get the best option for your drafting needs.

What are the drawing tools and their uses?

  • Mechanical pencils: These are durable with a range of hardness grades for precise drawing.
  • Technical pens: These specialized utensils create lines of consistent width.
  • Drawing board: This holds your paper in place to prevent movement, ensuring accurate work.
  • T-square: Use this tool with the drafting board to draw horizontal lines.

What equipment do you need for architecture?

Architecture students must acquire a variety of drafting supplies. Some essential items include:
  • A messenger bag to hold your laptop and other supplies
  • A sketchbook
  • Drafting pencils
  • Technical pens and erasable sketching pens
  • Steel ruler
  • Scale ruler
  • Drawing board
Designs require protractors, planes, triangles and scales to draw accurate proportions.

Do architects draw by hand?

Although architects use computer-aided design technology to create most designs, hand-drawing is still a crucial skill. This technique assists with the creative process and helps convey your vision with clarity, bringing your ideas to life. It also enables you to demonstrate your plans in a meeting or presentation setting quickly.

Architectural drawings contain details and a graphic of the construction elements. Mistakes can cause costly errors or delays. Invest in quality drafting supplies to ensure clarity, accuracy and ease of understanding.
