Dietzgen

Drafting paper has certain features that make it useful for architects, engineers, and anyone else who makes technical drawings. You can find it in a variety of sizes and styles. But because of the rise of Computer-Aided Design (CAD) systems that allow people to make technical drawings on a computer instead of drawing them by hand, the use of drafting paper has been in decline.

Final drawings must be done on archival-quality paper, so the image will endure and stay crisp for many years. It also needs to contrast well with the pen and pencil you use, which will make it easier to copy the drawing if needed. You’ll also need a variety of drafting tools that will allow you to make precise drawings that communicate clearly.

Vellum drafting paper is made out of cellulose fibers, which come from plants and trees. But it used to be made by stretching calf skin over a wooden frame, so it can be processed for writing. While animal-based vellum is still being manufactured, it’s a very time-consuming and expensive process. That’s why modern vellum is often made by machine with cellulose fibers.

Drafting paper can come in many different sizes, but there are some standard formats that are used for both architectural and engineering documents. The formats for architectural drawings include:

• ARCH A — 9 x 12 inches (228.6 x 304 millimeters)
• ARCH B — 12 x 18 inches (304.8 x 609.6 millimeters)
• ARCH C — 18 x 24 inches (457.2 x 609.6 millimeters)
• ARCH D — 24 x 36 inches (609.6 x 914.4 millimeters)
• ARCH E — 36 x 48 inches (914.4 x 1219.2 millimeters)

Engineering documents use the following formats:

• ANSI A — 8.5 x 11 inches (215.9 x 279.4 millimeters)
• ANSI B — 11 x 17 inches (279.4 x 431.8 millimeters)
• ANSI C — 17 x 22 inches (431.8 x 558.8 millimeters)
• ANSI D — 32 x 34 inches (558.8 x 863.6 millimeters)
• ANSI E — 34 x 44 inches (863.6 x 1117.6 millimeters)

If you’re looking for drafting paper made by Dietzgen or any other brand, feel free to look at what we have in stock.

While Dietzgen drafting tools were once known for being the best on the market, the company only makes paper products that can be used for large-format documents. Dietzgen paper is known for its quality, which is why many architects and engineers trust this brand. Some of the products made by Dietzgen include but may not be limited to:

• CAD paper
• Drafting vellum
• Blueprint paper supplies
• Plotter paper
• Azon paper

They make engineering paper that can be used by many well-known brands of wide-format copiers and printers, which include some of the following:

• HP
• Ricoh
• Samsung
• Oce
• Kip

Feel free to look at the broad selection we have at Engineer Supply, so you can find a product that will meet your specific needs.
