Most theodolites have a mirror light source that should now be opened. Look through its eyepiece and notice the three scales — vertical, horizontal, and fine adjustment. Use the adjustment knobs to align the line with the horizontal scale so that the object you wish to measure is positioned between the double lines.
5. Read the Horizontal Angle
You can now begin taking measurements by reading the horizontal angle that is indicated on the device. Look at the horizontal line and create a reference by lining it up with a tall landmark that’s easy to see. To do this, release the bottom clamp, position the landmark within the sight line, and secure the clamp again.
6. Read the Vertical Angle
Repeat the steps involve to obtain a horizontal measurement, but this time, adjust the vertical clamp. Release the vertical clamp and position the device to find the exact target you need to measure. Lock the clamp once again and use the adjustment knobs to fine-tune the precise point you want to measure. Look through the eyepiece to see the degrees, minutes, and seconds that it indicates. These coordinates will indicate the precise angle of measurement between the two points.
7. Anyone Can Use a Theodolite if They Know How It Works
Theodolites may at first seem mystifying to a beginner, and it’s true that they require more technical skill than many other kinds of survey tools. Despite this, knowing how to use theodolites is an important skill for anybody who wants to break into the field of surveying. Anybody who wants to learn how to use theodolites can master this skill if they follow the aforementioned steps and study the device closely.
Understand How to Use a Theodolite Correctly
Learning how to use a
theodolite is a great way to understand the basic concepts associated with surveying. It’s also a great way to get remarkably accurate angular measurements. If you’re wondering where to find the
best selection of theodolites, look no further than Engineer Supply. Call us at (800) 591-8907 for more information on our products and pricing.
Frequently Asked Questions
Is a theodolite the most accurate way to measure angles?
A theodolite is one of the most reliable and precise tools you can use for producing measurements, including angular measurements. Some say that it is indeed the most accurate, and it is more reliable than other tools such as compasses. A total station is reliable, too, and it uses a theodolite to generate measurements.
Do surveyors still use theodolites?
Yes, surveyors still use theodolites when they are gathering measurements on a survey site. Theodolites are not used as commonly as they were in the past, but they are still an important part of every surveyor’s toolbox.
Is a digital or manual theodolite better?
Digital theodolites have become increasingly popular thanks to the advent of new technology, and they may be more convenient than their manual predecessors. A digital theodolite offers digital readouts rather than graduated circles, and this may make it more accurate and easier to use.
Who uses theodolites?
In addition to surveyors, professionals such as civil engineers, construction managers, architects, and designers have all been known to use theodolites in their work. This is because all of these professionals rely on highly accurate measurements.
Are there different types of theodolites?
Yes, there are several different types of theodolites that you can use. In addition to manual and digital theodolites, you can choose from transit and non-transit theodolites. The former features a telescope that can rotate the trunnion axis, whereas the latter limits its rotation to a specific arc.
