What is the best drafting table?

Before you set up an architectural drafting table, you need to think about where you’re going to place it. You want to assemble it where you want to put it, instead of putting it together somewhere else and having to move it. Not only will it save you time and effort, but it will also give you a chance to see if the place you chose has enough space to accommodate your range of motion while you’re working.

The standard sizes for a drafting table include:

• 24” x 36”
• 30” x 42”
• 37.5” x 48”
• 37.5” x 72”

These sizes may not be ideal for your specific needs, so you might want to check some other available sizes. To make sure the table is large enough, you should think about the size of the paper that you plan to use (which should be at least two times larger).

The price of a drafting table will vary with each manufacturer. You can find one for as little as $100 to as much as $1,200. So, you should shop around to find one that meets your needs and fits your budget. Whether you’re looking for an adjustable drafting table or some other product, be sure to look at the broad selection we have at Engineering Supply.

Drawing paper needs to be placed on a drafting table by using a T-square. And once it’s in the right position, it’s attached to the board with masking tape or board clips. The T-square needs to be placed against the edge of the drafting table, and there can’t be any visible gaps. Otherwise, the paper won’t be set up in a way that will allow you to draw accurate horizontal and vertical lines. The paper needs to rest on the T-square before it can be attached to the table, so you can be sure that what you draw is accurate.

To attach a parallel bar to a drafting table, you’ll need to get a piece of nylon twine. Attach one end to the bottom left hook on the table and through the bottom left runner on the parallel bar. Continue the line through the bottom right runner to the top-right hook on the table. Keep running the line through the top left hook, and cross the twine to the bottom left runner. Pull the line across the parallel bar to the bottom right runner and through the top-right hook. Pull the line to make sure it has enough tension, and tie it to the bottom right hook. You also want to make sure the bladed doesn’t slip in any vertical direction before you tie it down.
